Honeywell ECS Series User Manual

Model IFP-2100/ECS Installation Manual LS10143-001SK-E
12-7
Zone-based AUX1 switch alarm UA Zone # +
1000
UANN001ZZZ 1 140 01 Zone #
Zone-based AUX1 switch alarm
restore
UH Zone # +
1000
UHNN001ZZZ 3 140 01 Zone #
Zone-based AUX1 switch trouble UT Zone # +
1000
UTNN001ZZZ 1 373 01 Zone #
Zone-based AUX1 switch trouble
restore
UJ Zone # +
1000
UJNN001ZZZ 3 373 01 Zone #
Zone-based AUX2 switch alarm UA Zone # +
2000
UANN002ZZZ 1 140 02 Zone #
Zone-based AUX2 switch alarm
restore
UH Zone # +
2000
UHNN002ZZZ 3 140 02 Zone #
Zone-based AUX2 switch trouble UT Zone # +
2000
UTNN002ZZZ 1 373 02 Zone #
Zone-based AUX2 switch trouble
restore
UJ Zone # +
2000
UJNN002ZZZ 3 373 02 Zone #
Point Events
Note: For IDP or SK devices, sensors 1–159 are reported as Points 1–159, mod-
ules 1–159 are reported as Points 201–359.
An unexpected SLC device has
been detected
pi Exp. ID XE Point # XENNXXPPPP 1 380 Exp. ID Point #
An unexpected SLC device has
been removed
pi Exp. ID XI Point # XINNXXPPPP 3 380 Exp. ID Point #
Auxiliary power disabled pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Auxiliary power enabled pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Auxiliary power Trouble pi Exp. ID FT Point # FTNNXXPPPP 1 320 Exp. ID Point #
Auxiliary power trouble restore pi Exp. ID FJ Point # FJNNXXPPPP 3 320 Exp. ID Point #
Background Music Switch is
Trouble
pi Exp. ID UT Point # UTNNXXPPPP 1 379 Exp. ID Point #
Background Music Switch is
Trouble Restored
pi Exp. ID UJ Point # UJNNXXPPPP 3 379 Exp. ID Point #
Background Music Switch is
Disabled
pi Exp. ID UB Point # UBNNXXPPPP 1 580 Exp. ID Point #
Background Music Switch is
Enabled
pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point #
CO Detector Trouble pi Exp. ID GT Point # GTNNXXPPPP 1 373 Exp. ID Point #
CO Detector Trouble Restore pi Exp. ID GJ Point # GJNNXXPPPP 3 373 Exp. ID Point #
CO Detector Disabled pi Exp. ID GB Point # GBNNXXPPPP 1 571 Exp. ID Point #
CO Detector Enabled pi Exp. ID GU Point # GUNNXXPPPP 3 571 Exp. ID Point #
Detector Alarm pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
Table 12-2: Reporting Formats Table
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA IFP-2100/ECS
Event Description Module
ID # (If
Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN -
panel ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
