Honeywell ECS Series User Manual

LS10143-001SK-E Reporting
12-8
Detector Alarm restore pi Exp. ID FH Point # FHNNXXPPPP 3 110 Exp. ID Point #
Detector Disabled pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Detector Enabled pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Detector Trouble pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
Detector Trouble restore pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
Detector CO Alarm pi Exp. ID GA Point # GANNXXPPPP 1 162 Exp. ID Point #
Detector CO Alarm Restore pi Exp. ID GH Point # GHNNXXPPPP 3 162 Exp. ID Point #
Detector CO Supervisory Alarm pi Exp. ID GS Point # GSNNXXPPPP 1 200 Exp. ID Point #
Detector CO Supervisory Alarm
Restore
pi Exp. ID GR Point # GRNNXXPPPP 3 200 Exp. ID Point #
ECS Alarm # Point Alarm pi Exp. ID QA (EPPP) E -
Emergen-
cy #
PPP -
Point #
QANNXXEPPP 1 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Alarm Restore pi Exp. ID QH (EPPP) E -
Emergen-
cy #
PPP -
Point #
QHNNXXEPPP 3 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Alarm # Point Trouble Re-
store
pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Alarm # Point Disabled pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Alarm # Point Enabled pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS Supervisory/Tamper Alarm pi Exp. ID QS Point # QSNNXXPPPP 1 241 Exp. ID Point #
ECS Supervisory/Tamper Alarm
Restore
pi Exp. ID QR Point # QRNNXXPPPP 3 241 Exp. ID Point #
ECS Supervisory/Tamper Trou-
ble
pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Supervisory/Tamper Trou-
ble
Restore
pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Supervisory/Tamper Dis-
abled
pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Supervisory/Tamper En-
abled
pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS NAC Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS NAC Trouble Restored pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
Table 12-2: Reporting Formats Table
SIA Reporting Format
Contact ID Reporting Format
SIA pi Modifier SIA IFP-2100/ECS
Event Description Module
ID # (If
Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN -
panel ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
