9 Safety Bus Manual — P/N LS10177-000HI-E:B 02/21/2019
Useful Information Programming Features Subject to AHJ Approval
Programming Features Subject to AHJ Approval
This product incorporates field-programmable software. The features and/or options below must be
approved by the local AHJ.
Description
Permitted
in UL? Possible Settings
Settings Permitted
in UL 864 Comment
Embedded Logic (ECM Module)
Fault/Disable status of I/Os Yes Does Not prevent
release,
Prevents release
Does not prevent
release
Reset inhibition time (ECM module) Yes 0-30 Minutes,
1-30 Minutes
0-30 Minutes Releasing circuits can be reset0
minutes to 30 minutes after
discharge has operated.
Manual discharge delay (ECM
Module)
Yes 0-30 Seconds,
0-60 Seconds
0-30 Seconds
Hold/Abort Mode (ECM Module) Yes A,B,C C Continues to count down upon
Abort, but stops and holds at below
10 seconds until release of the
Abort switch. Upon release of the
Abort switch, the time resumes the
countdown at less than 10 seconds.
Discharge delay time after
Hold/Abort is released in Mode C
(ECM Module) Yes
Yes Less than 10
seconds,
10 seconds
less than 10 seconds
Aut. Discharge delay Yes 0-60 seconds 0-60 seconds The Automatic Discharge Delay
must be set to a maximum of 55
seconds when releasing devices
utilizing the F7011 communication
ring or F7012 SLC are employed.
