Performance Series Indoor Day/Night H.264 IP Camera User Guide
Document 800-09312V2 Rev A 63
08/2012
Note To turn off camera field of view change detection, select Disable in the Scene
Change Threshold list. Disable is the default value.
Note You must click Apply after you make changes to any settings to save those
changes. Settings are not saved unless you click Apply.
Configuring Video Motion Detection
For motion detection, an Administrator can enable and configure up to 5 zones within a
scene. The enabled and configured zones will be monitored for motion.
1. Click the Region drop-down menu, then select a region from the five available.
2. Click the VMD drop-down arrow, and select Enable.
The Regions appear in their default positions.
3. Click Apply.
4. Click and drag the box to resize and place it over the camera image.
5. Select the sensitivity level (High, Medium, Low).
Figure 4-14 Motion Detection: Defining a Region
