Document 800-09312V2 Rev A 73
08/2012
Specifications
Note These specifications refer to all models, except where otherwise noted.
Specifications are subject to change without notice.
Video Signal Specifications NTSC PAL
Scanning System: Progressive
Image Sensor: 1/4” CMOS
Number of Pixels (H x V): 1280 x 720 (HD45IP/HD45IPX)
640 x 480 (HD44IP/HD44IPX)
Minimum Illumination: 0.25 lux @ 50 IRE, F1.4
0.11 lux @ 30 IRE, F1.4
Video Output (local): 1.0 Vp-p @ 75 Ohms
S/N Ratio: 50 dB or more (AGC off)
Auto Gain Control (AGC): Off/On, selectable (10 – 40 dB)
Auto Electronic Shutter (ELC): 1/60 – 1/24,500 sec 1/50 – 1/24,500 sec
Automatic Lens Iris Control: DC Iris level 1 – 25
White Balance (AWB): AWC, AWC Push, Manual
Lens Type: 3.3 mm to 12.0 mm Vari-focal Auto Iris, F1.4
Electrical Specifications
Input Voltage: 24 V AC, PoE IEEE 802.3af, Class 1
Input Voltage Range: 17 – 28 V AC
Surge Suppression: 1.5 kW transient
Power Consumption: 3.5 W (max)
Mechanical
Dimensions (W x H): See diagrams (Figure C-1, Figure C-2)
Weight: 1.0 lb (0.448 kg) camera only
Construction: Housing: Polycarbonate
Finish: Matte texture, off-white
Connectors: Local Video Output (AUX): 2-pin Molex connector
Power Input: Removable screw block
Network: RJ45 connector
Environmental
Temperature: Operating: 14°F to 122°F (-10°C to 50°C)
Storage: -40°F to 158°F (-40°C to 70°C)
Relative Humidity: 0% to 85%, non-condensing
