800-13897 - A - 01/2013
Specifications | 129
Dimensions
LINE IN
AUDIO OUT
RS-232
VGA
LAN
HDMI
ALARM IN
RS-485 ALARM OUT
12V
POWER
LOOP OUT
AUD IO I NVIDEO OUT VIDEO IN
4-Channel HRG
8-Channel/16-Channel HRG (HRG16X shown)
12.4" (315 mm)
9.1" (230 mm)
17.5" (455 mm)
11.4" (290 mm)
1.8"
(45 mm)
1.8"
(45 mm)
1.8"
(45 mm)
1.8"
(45 mm)
