800-13897 - A - 01/2013
Introduction | 31
Using the Virtual Keyboard
When a mouse is used to perform a task on the HRG DVR, clicking on a text input field brings
up the Virtual Keyboard.
Figure 1-5 Virtual Keyboard
Rear Panel
Use these diagrams to make the rear panel connections.
4-Channel HRG Rear Panel Connections and Switches
Figure 1-6 4-Channel HRG Rear Panel Connections and Switches
Table 1-4 Virtual Keyboard Controls
Virtual key Name Function
Lowercase Indicates that lowercase
input is being used.
Uppercase Indicates that uppercase
input is being used.
Switch to lowercase Switch to lowercase input.
Switch to uppercase Switch to uppercase input.
Number Indicates that number input is
being used.
Symbols Switch to symbols input.
Backspace Delete a character in front of
the cursor.
Enter Confirm selection.
ESC Exit out of the virtual
keyboard.
To Next Page
