Page 100 ST 800 Series HART/DE Option User’s Manual Revision 5.0
10.6 Basic Setup Page
Pressure Transfer Fn:
Allows selecting Transfer function; Linear or Square Root.
Low Flow Cutoff Mode:
Allows selecting the User Config Mode and entering the Low Flow Cutoff breakpoint from 0-25% to
get the needed signal conditioning. Refer to Table 11 for more details
Device Information
Allows access to both read only parameters and read/write parameters.
Provides access to Message, Clear Message and Maint Mode.
“Transmitter Messaging” and
“Maintenance Mode”
