Revision 5.0 ST 800 Series HART/DE Option User’s Manual Page 33
Device Configuration and Parameter Descriptions
Table 11 lists descriptions of all parameters for a HART Transmitter with the Online tab menu path.
The same parameters may be accessed via the Shortcuts menu under the My Device tab.
Table 11 – HART Transmitter Parameters
Displays a pictorial representation of the
current device status
Online/Honeywell
Logo
Photograph of an ST 800 Pressure
Transmitter along with the official “Honeywell”
Online/PV Meter Displays a gauge meter representation of the
current value of the Primary Variable
Displays the current value of the Primary
Variable (pressure input) in user selected
Online/SV Meter Displays a gauge meter representation of the
current value of the Secondary Variable
Displays the current value of the Secondary
Variable (meter body temperature) in user
selected engineering units
Displays a gauge meter representation of the
current value of the Analog Output
Displays the current value of Analog Output
in mA
Online/TV Displays the current value of the Tertiary
Variable (static pressure) in psi
Displays the current value of transmitter
Output in %
Displays the current value of the Lower Range
Value (input which represents 0% output) in
user selected engineering units.. This value
may be configured to any value within the
Online/PV URV Displays the current value of the Upper Range
Value (input which represents 100% output) in
user selected engineering units. This value
may be configured to any value within the
Displays the Lower Range Limit of the
transmitter in user selected engineering units.
Displays the Upper Range Limit of the
transmitter in user selected engineering units.
Online/ PV LTL Displays the Lower Transducer Limit of the
transmitter in user selected engineering units.
Displays the Upper Transducer Limit of the
transmitter in user selected engineering units.
