Page 34 ST 800 Series HART/DE Option User’s Manual Revision 5.0
Online/Device
Setup/Basic Setup/
Pressure Xfer Fn
Pressure Transfer function:
Select the pressure transfer function for
calculated output:
Linear: (output scaled linearly per
configured range)
Square Root : (output scaled as square
root conversion per configured range -
for flow measurements)
Transfer Function Image Diagram of a flow application (square root
transfer function) to exemplify dual-slope low-
flow cutoff behavior with uni-directional flow
Online/Device
Setup/Basic Setup/
Low flow Cutoff (Sq
Root)
Low Flow Cutoff Mode For Square Root (Transfer function)
configurations only, choose the operating
mode to determine the low flow cutoff
breakpoint:
Dual slope: (breakpoint determined by
dual slope calculation)
User configuration: (breakpoint defined
Breakpoint
When “User Configuration” is selected for Low
Flow Cutoff Mode, enter the desired
Setup/Basic Setup/
ST 800 Device
Photograph of an ST 800 Pressure
Transmitter
Online/Device
Setup/Basic Setup/
Diagram representing typical connections for
power and communications for the ST 800
Online/Device
Setup/Basic Setup/
Parts assembly diagram of an ST 800
Pressure Transmitter
Online/Device
Setup/Basic Setup/
Device Information
Photograph of an ST 800 Pressure
Transmitter along with the official “Honeywell”
Displays Manufacturer of the ST 800 Pressure
Transmitter: Honeywell International
Displays Model number of the ST 800
Pressure Transmitter: ST 800
Enter the date of site installation. This is a
one-time only configuration.
Displays Meter Body Type of the ST 800
Pressure Transmitter. Possible types are:
DP: Differential Pressure
AP: Absolute Pressure
Displays the Meter Body ID number of the ST
800 Pressure Transmitter
Enter tag identification up to eight
alphanumeric characters.
Enter a long tag name up to 32 alphanumeric
characters.
Configuration Change Counter – this counter
keeps track of the number of times any
configuration parameter has been changed
