Honeywell ST 800 Series User Manual

Page 36 ST 800 Series HART/DE Option User’s Manual Revision 5.0
Online/Device
Setup/Basic Setup/
Device Information
(Continued …)
Device ID
Displays the HART unique long address of
the ST 800 Pressure Transmitter
Final Asmbly num
Displays the final assembly number of the ST
800 Pressure Transmitter
Universal rev
Displays the HART Universal Revision of the
ST 800 Pressure Transmitter
Fld dev rev
Displays Field Device Revision of the ST 800
Pressure Transmitter
Software rev
Displays the Electronics Board Software
Revision of the ST 800 Pressure Transmitter
Loop mA
Select the Loop Current Mode configuration:
“Enable”: enables loop current mode
(analog output will operate as a 4 to
20 mA signal consistent with the
transmitter output)
“Disable”: disables loop current mode
(analog output will be fixed at 4 mA)
PV Units
Select one of the pre-programmed
engineering units. ST 800 Transmitters with
inches of water ranges are factory calibrated
using pressure referenced to 39.2
o
F (4
o
C).
Pressure readings can be displayed in the
following engineering units:
inH
2
O inHg
ftH
2
O
mmH
2
O mmHg psi
bar mbar
g/cm
2
kg/cm
2
Pa
kPa
torr atm
MPa
inH
2
O @ 4
o
C mmH
2
O@4
o
C
inH
2
O @ 60
o
F
PV Damping
Enter a value for damping of the device
output. Entries may be any value from 0.00
to 32.00 seconds.
SV Units
Select the desired unit for measurement of
the Secondary Variable (Meter Body
Temperature). Selections available are:
o
C
,
o
F,
o
R, Kelvin.
Write Protect
Displays the current configuration of the write
protect function. Write Protect is “Enabled” if
either the write protect jumper on the
electronics board is in the “ON” position or
the firmware write protect has been enabled.
