Primary/Alternate Data Formats Primary Data Format ALTFNM0 185
Data Format 1 ALTFNM1 185
Data Format 2 ALTFNM2 185
Data Format 3 ALTFNM3 185
Single Scan Data Format Change Single Scan-Primary
Data Format
VSAF_0 185
Single Scan-Data Format 1 VSAF_1 186
Single Scan-Data Format 2 VSAF_2 186
Single Scan-Data Format 3 VSAF_3 186
Symbologies
All Symbologies All Symbologies Off ALLENA0 188
Codabar Default All Codabar
Settings
CBRDFT 188
Off CBRENA0 188
*On CBRENA1 188
Codabar Start/Stop Char. *Don’t Transmit CBRSSX0 189
Transmit CBRSSX1 189
Codabar Check Char. *No Check Char. CBRCK20 189
Validate, But Don’t Transmit CBRCK21 189
Validate, and Transmit CBRCK22 189
Codabar Concatenation *Off CBRCCT0 190
On CBRCCT1 190
Require CBRCCT2 190
Codabar Message Length Minimum (2 - 60) *4 CBRMIN## 190
Maximum (2 - 60) *60 CBRMAX## 190
Code 39 Default All Code 39
Settings
C39DFT 191
Off C39ENA0 191
*On C39ENA1 191
Code 39 Start/Stop Char. *Don’t Transmit C39SSX0 191
Transmit C39SSX1 191
Code 39 Check Char. *No Check Char. C39CK20 191
Validate, But Don’t
Transmit
C39CK21 191
Validate,
and Transmit
C39CK22 191
Code 39 Message Length Minimum (0 - 48) *0 C39MIN## 192
Maximum (0 - 48) *48 C39MAX## 192
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
