292 Xenon/Granit User Guide
Code 39 Append *Off C39APP0 192
On C39APP1 192
Code 32 Pharmaceutical (PARAF) *Off C39B320 193
On C39B321 193
Code 39 Full ASCII *Off C39ASC0 193
On C39ASC1 193
Code 39 Code Page C39DCP 193
Interleaved 2 of 5 Default All Interleaved
2 of 5 Settings
I25DFT 194
Off I25ENA0 194
*On I25ENA1 194
Interleaved 2 of 5 Check Digit *No Check Char. I25CK20 194
Validate, But Don’t
Transmit
I25CK21 194
Validate, and Transmit I25CK22 194
Interleaved 2 of 5 Message Length Minimum (2 - 80) *4 I25MIN## 195
Maximum (2 - 80) *80 I25MAX## 195
NEC 2 of 5 Default All NEC
2 of 5 Settings
N25DFT 195
Off N25ENA0 195
*On N25ENA1 195
NEC 2 of 5 Check Digit *No Check Char. N25CK20 196
Validate, But Don’t
Transmit
N25CK21 196
Validate, and Transmit N25CK22 196
NEC 2 of 5 Message Length Minimum (2 - 80) *4 N25MIN## 196
Maximum (2 - 80) *80 N25MAX## 196
Code 93 Default All Code 93
Settings
C93DFT 197
Off C93ENA0 197
*On C93ENA1 197
Code 93 Message Length Minimum (0 - 80) *0 C93MIN## 197
Maximum (0 - 80) *80 C93MAX## 197
Code 93 Append On C93APP1 197
*Off C93APP0 197
Code 93 Code Page Code 93 Code Page C93DCP 198
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
