Honeywell Xenon Series User Manual

Xenon/Granit User Guide 297
GS1 DataBar Limited Default All GS1 DataBar Limited
Settings
RSLDFT 220
Off RSLENA0 220
*On RSLENA1 220
GS1 DataBar Expanded Default All GS1 DataBar
Expanded Settings
RSEDFT 221
Off RSEENA0 221
*On RSEENA1 221
GS1 DataBar Expanded Msg.
Length
Minimum (4 - 74) *4 RSEMIN## 221
Maximum (4 - 74) *74 RSEMAX## 221
Trioptic Code *Off TRIENA0 221
On TRIENA1 221
Codablock A Default All Codablock A Settings CBADFT 222
*Off CBAENA0 222
On CBAENA1 222
Codablock A Msg. Length Minimum (1 - 600) *1 CBAMIN### 222
Maximum (1 - 600) *600 CBAMAX### 222
Codablock F Default All Codablock F Settings CBFDFT 223
*Off CBFENA0 223
On CBFENA1 223
Codablock F Msg. Length Minimum (1 - 2048) *1 CBFMIN#### 223
Maximum (1 - 2048) *2048 CBFMAX#### 223
Label Code On LBLENA1 223
* Off LBLENA0 223
PDF417 Default All PDF417 Settings PDFDFT 224
*On PDFENA1 224
Off PDFENA0 224
PDF417 Msg. Length Minimum (1-2750) *1 PDFMIN#### 224
Maximum (1-2750) *2750 PDFMAX#### 224
MacroPDF417 *On PDFMAC1 225
Off PDFMAC0 225
MicroPDF417 Default All Micro PDF417 Settings MPDDFT 225
On MPDENA1 225
*Off MPDENA0 225
MicroPDF417 Msg. Length Minimum (1-366) *1 MPDMIN### 225
Maximum (1-366) *366 MPDMAX### 225
GS1 Composite Codes On COMENA1 226
*Off COMENA0 226
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
