148
Table 10 Port object attributes
Attribute Descri
p
tion
Port WWN WWN of the port.
Supported FC4 types
• FCP—Fibre Channel Protocol.
• GS3.
• IP.
• LLC/SNAP.
• NPV.
• SNMP.
• SW-ILS.
• VI.
Supported speed
The supported speed can be one or more of the following options:
• 1 Gbps.
• 2 Gbps.
• 4 Gbps.
• 8 Gbps.
• 10 Gbps.
• 16 G b p s .
• 20 Gbps.
• 32 Gbps.
• 40 Gbps.
Current speed
The current speed can only be one of the following options:
• 1 Gbps.
• 2 Gbps.
• 4 Gbps.
• 8 Gbps.
• 10 Gbps.
• 16 G b p s .
• 20 Gbps.
• 32 Gbps.
• 40 Gbps.
Maximum frame size Maximum frame size supported by the port.
OS device name Operating system name of the port.
Host name Host name of the node where the port resides.
Displaying and maintaining FDMI
Execute display commands in any view.
Task Command
Display the FDMI database information.
display fdmi database [ vsan vsan-id ] [ hba-id hba-id ]
[ verbose ]
