92
# Change Ethernet interface Ten-GigabitEthernet 1/0/1 into FC interface FC 1/0/1.
[SwitchB] interface ten-gigabitethernet 1/0/1
[SwitchB-Ten-GigabitEthernet1/0/1] port-type fc
# Configure the mode of interface FC 1/0/1 as E.
[SwitchB-Fc1/0/1] fc mode e
# Configure interface FC 1/0/1 to autonegotiate the speed.
[SwitchB-Fc1/0/1] speed auto
# Configure the trunk mode of interface FC 1/0/1 as On, and assign interface FC 1/0/1 to
VSAN 1 as a trunk port.
[SwitchB-Fc1/0/1] port trunk mode on
[SwitchB-Fc1/0/1] port trunk vsan 1
# Enable FSPF for interface FC 1/0/1.
[SwitchB-Fc1/0/1] undo fspf silent vsan 1
[SwitchB-Fc1/0/1] quit
# Enable FCoE for VLAN 10, and map VLAN 10 to VSAN 1.
[SwitchB] vlan 10
[SwitchB-vlan10] fcoe enable vsan 1
[SwitchB-vlan10] quit
Verifying the configuration
# Display FSPF neighbor information on Switch A.
[SwitchA] display fspf neighbor
FSPF neighbor information of VSAN 1(01):
Interface NbrDomain IfIndex NbrIfIndex Dead Time State
Fc1/0/1 2 0x68 0x68 00:01:06 Full
# Display the FC routing table on Switch A.
[SwitchA] display fc routing-table vsan 1
Routing Table: VSAN 1
Destinations : 5 Routes : 5
Destination/mask Protocol Preference Cost Interface
0x020000/8 FSPF 20 1062 Fc1/0/1
0xfffc01/24 DIRECT 0 0 InLoop0
0xfffffa/24 DIRECT 0 0 InLoop0
0xfffffc/24 DIRECT 0 0 InLoop0
0xfffffd/24 DIRECT 0 0 InLoop0
# FCping Switch B from Switch A.
[SwitchA] fcping fcid fffc02 vsan 1
FCPING fcid 0xfffc02: 128 data bytes, press CTRL_C to break.
Reply from 0xfffc02: bytes = 128 time = 1.102 ms
Reply from 0xfffc02: bytes = 128 time = 0.276 ms
Reply from 0xfffc02: bytes = 128 time = 0.253 ms
Reply from 0xfffc02: bytes = 128 time = 0.270 ms
Reply from 0xfffc02: bytes = 128 time = 0.247 ms
--- 0xfffc02 fcping statistics ---
5 packet(s) transmitted
5 packet(s) received
