Acquiring a 12-Lead ECG
6-9
To Acquire a 12-Lead ECG:
If your HP CodeMaster 100 with 12-Lead is already configured, you can acquire an
ECG by performing the following steps:
1 Connect the 12-Lead ECG cable to the patient.
2 Turn the Energy Select control to Monitor On.
3
Prepare the patient and apply the electrodes, as described in “Preparing the
Patient” on page 6-10.
4 Check the signal quality on all leads.
5
Press the ID key and enter patient ID information.
6
Press the 12-Lead key to obtain an ECG.
If you are using HP ACI-TIPI or TPI, the system prompts you for any missing
information required for HP ACI-TIPI or TPI. See “Using HP ACI-TIPI” on
page 6-18 and “Using HP TPI” on page 6-19.
The status messages
Acquiring ECG...
,
Processing...
,
Analyzing... Storing ECG...
, and
Printing...
are displayed.
Wait for the report to print.
If you have configured the 12-Lead option to Auto Send, the system displays the
telephone directory.
If the memory is full and you attempt to store a new ECG, the system will
“auto delete” the oldest stored ECG.
.
NOTE
