HP M2478A DC External Power Module
14-11
14HP M2478A DC External Power Module
For use only with CodeMaster 100 Defibrillator/Monitor.
Size: 1.75 in H by 5.5 in W by 3.25 in D (4.44 mm H by 14.0 mm W by
8.25 mm D).
Weight: 1.1 lb (0.5 kg).
Input cable: 10 ft (3.0 m).
Output cable: 3.0 ft (0.91 m).
Input: 11.8–16 V DC, 1.0 A, 12 W; 8 A, 100 W maximum.
Battery charging output : 12 V DC, 1.0 A, 12 W; 90.0 mA, 1.1 W trickle.
Instrument operation output: 12 V DC, 1.0 A, 12 W; 7 A, 85 W maximum.
Charge time: With defibrillator/monitor turned to Off/Standby: typically four
hours—HP M2476B 2.5 Ah Battery, typically six hours—HP M2477B 4.0 Ah
Battery.
Recommended charging temperature: 5° C to 35° C.
Environmental operating conditions: 0° C to 55° C, 5 to 90% relative humidity,
non-condensing, 15000 ft altitude (500 hPa).
Transport and storage: -40° C to 70° C, 10 to 100% relative humidity including
condensation, 15000 ft altitude (500 hPa).
