Operating Controls and Indicators
1-13
SpO
2
Operating Controls
This topic details the SpO
2
operating controls associated with the SpO
2
feature on the HP CodeMaster 100. Refer to Figure 1-8.
Figure 1-8
SpO
2
Operating Controls 1-8
SpO2
On/Off
SpO
2
Alarm
SpO2 ECG Input
QRS
M2475-B0005
Sp0
2
Connector
