Setting Up the CodeMaster 100
2-5
ECG Input Connector
The HP patient cable supplied with this device, or an HP approved
substitute patient cable, is an integral part of the defibrillator/monitor
safety features. Using any other patient cable may compromise
defibrillation protection as well as performance.
Only qualified personnel may service the device.
The ECG Input connector on the defibrillator is a 12-pin connector.
Connecting the Patient Cable The 3-wire, 5-wire, and 10-wire patient cables
connect to the ECG Input connector located on the front right side of the
defibrillator, below the QRS volume and pacer controls. The patient cable plug has
12-pins. To install the patient cable (Figure 2-3):
1 Align the keyed cable plug with the slot in the ECG Input connector.
2 Push the cable plug firmly into the ECG Input connector.
If Leads is selected as the ECG source, the message
LEADS OFF
will appear on the
monitor display if the patient electrode becomes disconnected. A dashed line
appears on the display in place of an ECG trace.
