Defibrillator/Monitor
14-9
Battery
HP M2476B 2.5 amp-hour battery
Type: Rechargeable nickel-cadmium battery, 2.5 Ah, 12 V nominal.
Capacity:
M2475B Standard: 2500 mAH; 2.5 hours ECG monitoring or 50 full-energy
discharges or 1.75 hours combined ECG and SpO2 monitoring while pacing.
M2475B with the 12-Lead Option: 2500 mAH; 2.0 hours ECG monitoring or 50
full-energy discharges or 1.5 hours combined ECG and SpO2 monitoring while
pacing.
Battery Indicators: LOW BATTERY warning message appears on the monitor
when approximately 30 minutes of battery capacity remains.
Battery dimensions: 3.35 in H by 2.96 in W by 7.25 in D (85 mm H by 75 mm W
by 184 mm D).
Battery weight: 2.7 lb (1.22 kg).
Battery storage: Range of -30 to 50°C. Should not be stored above 35°C for
extended periods of time.
HP M2477B 4.0 amp-hour battery
Type: Rechargeable nickel-cadmium battery, 4.0 Ah, 12 V nominal.
Capacity:
M2475B Standard: 4000 mAH; 4 hours ECG monitoring or 75 full-energy
discharges or 3 hours combined ECG monitoring while pacing.
M2475B with the 12-Lead Option: 4000 mAH; 3 hours ECG monitoring or 75 full-
energy discharges or 2.5 hours combined ECG monitoring while pacing.
Battery Indicators: LOW BATTERY warning message appears on the monitor
when approximately 30 minutes of battery capacity remains.
Battery dimensions: 3.34 in H by 2.96 in W by 7.25 in D (85 mm H by 75 mm W
by 185 mm D).
Battery weight: 4.3 lb (1.95 kg).
