Transmitting a 12-Lead ECG
10-10
10Transmitting a 12-Lead ECG
To transmit an ECG:
1 Connect the cellular or landline connection cable to the modem.
2 Select the ECGs to send. Press the Send key or select Send ECGs from the Main
Menu. The Send ECG Display appears:
Press F1 or F2 to highlight the ECGs. Press F4. The telephone directory
appears.
Immediately after an ECG has been acquired and printed, it can be transmitted by
pressing the
Send button on the key pad. This will take you to the Telephone
Directory screen. Once in the Telephone Directory, use the Arrow button on the key
pad to highlight the destination for which you want to send the ECG and press the
Send softkey or the Send button on the keypad again.
If Auto Send Acquired ECG has been enabled, then you will automatically be
taken to the Telephone Directory after the ECG has been acquired and printed.
Select the destination and press either the Send softkey or the Send button on
the keypad.
Send ECGs (2 ECGs Stored)
Screen 1 of 1
Name/ID Time and Date
*Frank Smith
ID: 12345678 10:02 10-Apr-97
Charlotte Stephens
ID: 87654321 10:00 10-Apr-97
=Sent *=Selected
Select Send
Select All ECGs Exit
F1 F2 F3 F4 F5
NOTE
