7UDQVPLWWLQJ'DWDIURPWKH/HDG2SWLRQ
Using Cellular Communications
10-8
Figure 10-4
Standard Cellular Connection (Internal Modem)
10-4
Cellular
Internal Modem
RJ11C
Transmit Receiving Site
Cellular
Data Interface
Adapter
(RJ11C Adapter)
Cellular
Bag Phone
(3 watt)
Personal Computer
running ECG Manager
(M1765A) or Event
Summary Host
CodeMaster 100
with 12-Lead Option
