Glossary
G
general-purpose flexible adapter
A cable assembly that connects the
signals from an elastomeric probe
adapter to an analysis probe.
Normally, a male-to-male header or
transition board makes the
connections from the general-
purpose flexible adapter to the
analysis probe.
H
high-density adapter cable A
cable assembly that delivers signals
from an analysis probe hardware
interface to the logic analyzer pod
cables. A high-density adapter cable
has a single Mictor connector that is
installed into the analysis probe, and
two cables that are connected to
corresponding odd and even logic
analyzer pod cables.
high-density termination adapter
cable Same as a high-density
adapter cable, except it has a
termination in the Mictor connector.
J
jumper Moveable direct electrical
connection between two points.
M
mainframe logic analyzer A logic
analyzer that resides on one or more
board assemblies installed in an
HP 16500, HP 1660-series, or
HP 16600A/700A-series mainframe.
male-to-male header A board
assembly that makes point-to-point
connections between the female pins
of a flexible adapter or transition
board and the female pins of an
analysis probe.
P
preprocessor See analysis probe.
pod A collection of logic analyzer
channels associated with a single
cable and connector.
preprocessor interface See
analysis probe.
probe adapter See elastomeric
probe adapter.
processor probe See emulation
probe.
prototype analyzer The
HP 16505A prototype analyzer acts
as an analysis and display processor
for the HP 16500B/C logic analysis
