Chapter 2: Installing the Emulation Module
Equipment and Requirements
Equipment and Requirements
Supplied Equipment and Software
The emulation module includes:
• An HP 16610A emulation module.
• Firmware for the emulation module and/or updated software for the
Emulation Control Interface on a CD-ROM.
• A target interface module (TIM) circuit board.
The target interface module (TIM) is used to connect the emulation
module to a debug port in the target system.
The target interface module (TIM) is not needed when using the
HP E2490A analysis probe for MPC505/509 microprocessors because the
target interface module’s functionality is already built into the analysis
probe.
• A 50-pin ribbon cable for connecting the emulation module to the target
interface module (TIM) (or to the HP E2490A analysis probe).
• A 10-pin ribbon cable for connecting the target interface module (TIM) to
a debug port connector in the target system.
• One Torx T-10 and one Torx T-15 screwdriver.
• An emulation module loopback test board (HP part number E3496-66502)
•This User’s Guide.
