16
Chapter 1: Installing the Emulation Probe
Equipment and Requirements
Equipment and Requirements
Listed below are:
• Equipment and software supplied with the emulation probe.
• Additional equipment and software required by the emulation probe.
Supplied Equipment and Software
The emulation probe includes:
• An emulation probe.
• A 12V power supply for the emulation probe.
•A power cord.
• A target interface module (TIM) circuit board.
The target interface module (TIM) is used to connect the emulation probe
to a debug port connector in the target system.
The target interface module (TIM) is not needed when using the
HP E2490A analysis probe for MPC505/509 microprocessors because the
target interface module’s functionality is already built into the analysis
probe.
• A 50-pin ribbon cable for connecting the emulation module to the target
interface module (TIM) (or to the HP E2490A analysis probe).
• A 10-pin ribbon cable for connecting the target interface module (TIM) to
a debug port connector in the target system.
• Emulation Control Interface software.
• An emulation probe loopback test board (HP part number E3496-66502).
•This User’s Guide.
