44
Chapter 2: Installing the Emulation Module
Overview of Installation and Setup
Overview of Installation and Setup
Follow these steps to connect your equipment.
1 Check that you received all of the necessary equipment. See
“Equipment and Requirements” on page 46.
2 Disconnect power from the target system and logic analyzer
before you make or break connections.
3 Install the emulation module into the logic analysis system. See
“Installing into a Logic Analysis System” on page 48.
4 Install software on the logic analysis system. See “Installing
Software” on page 54.
5 Update the emulation module’s firmware to give it the proper
“personality” for the microprocessor it will connect to. See
“Updating Emulation Module Firmware” on page 56.
6 Connect the emulation module to your target system. See the
“Connecting to a Target System” chapter on page 63.
7 Configure the emulation module. See the “Configuring the
Emulation Probe/Module” chapter on page 75.
