67
Chapter 3: Connecting to a Target System
Designing the Target System for an Emulation Probe/Module
MPC555 Debug Port Connector, Option 3
For maximum I/O configuration:
The E3497-66502 target interface module (TIM) requires 10k ohm
pull-up resistors on pins 1 and 6.
The E3497-66503 target interface module (TIM) has 10k ohm pull-up
resistors on pins 1 and 6.
Bit 13 of the SIUMCR (0x002fc000) is set to enable FRZ. Software must
not change this bit.
Use the following commands to configure the emulation probe/module
for this configuration:
cf proc=MPC555
cf dbgconfig=3
rst -m
SYPCR Register
SYPCR register is a write once register containing software watchdog
timers.
The cf_sypcr register default value of 0xffffff88 is loaded into SYPCR
on the reset->break (or rst -m) sequence of commands.
This disables the watchdog timer. If another value of SYPCR needs to
be loaded, change the cf_sypcr register before issuing the reset->break
sequence of commands.
The reset->run sequence does not copy cf_sypcr into the real SYPCR
on the processor which may cause debugging to be unstable.
6*3,2)5=375
■■
65(6(7
*1'
■■
7&.B'6&.
*1'
■■
6*3,2)5=375
+5(6(7
■■
7',B'6',
9RG
■■
7'2B'6'2
