66
Chapter 3: Connecting to a Target System
Designing the Target System for an Emulation Probe/Module
Use the following commands to configure the emulation probe/module
for this configuration:
cf proc=MPC555
cf dbgconfig=1
rst -m
NOTE: The MIOS1TPCR (0x0030 6800) register is modified to configure J18 and K18
as VFLS0/1 pins. Software must not modify this register.
Option 1 is recommended because it leaves Program Trace pins for full
analysis support. The other two options sacrifice watchpoint pins or
program trace pins, thus forcing you to trade off analysis features.
MPC555 Debug Port Connector, Option 2
For maximum external bus capability:
The E3497-66502 (as well as the E3497-66503) target interface
module (TIM) is compatible with the MPC555 processor debug port.
Use the following commands to configure the emulation probe/module
for this configuration:
cf proc=MPC555
cf dbgconfig=2 (default probe setting)
rst -m
,:39)/6
■■
65(6(7
*1'
■■
7&.B'6&.
*1'
■■
,:39)/6
+5(6(7
■■
7',B'6',
9RG
■■
7'2B'6'2
