138
Chapter 6: Solving Problems
Solving Emulation Probe Problems
series logic analysis system. The LAN tests for an emulation probe can
only be executed through the RS-232 port.
To fully test the emulation probe, you will need to run the PV test with
several hardware configurations:
• For the BREAK IN, TRIGGER OUT BNC FEEDBACK TEST, connect a
coaxial cable between BREAK IN and TRIGGER OUT.
To run the performance verification tests using
the logic analysis system
1 End any Emulation Control Interface or debugger sessions.
2 Disconnect the 50-pin cable from the emulation probe, and plug
the loopback test board (HP part number E3496-66502) into the
emulation probe.
3 In the system window, click the emulation probe and select
Performance Verification.
4 Click Start PV.
The results will appear on screen.
To run complete performance verification tests
for an emulation probe
The LAN tests can only be executed through the RS-232 port. The
remainder of this section assumes that the tests are being run from a
terminal emulator connected to the RS-232 port.
1 Disconnect the 50-pin cable from the emulation probe, and plug
the emulator loopback test board (HP part number E3496-
66502) directly into the emulator. Do not plug anything into the
other end of the emulator loopback test board.
