81
Chapter 4: Configuring the Emulation Probe/Module
Setting the MPC5xx Configuration Options
Setting the MPC5xx Configuration Options
You must configure the processor probe to work with your target
system.
The following options can be configured using the Emulation Control
Interface or using built-in commands:
•Processor type.
Processor clock speed.
Debug port connection type (MPC555 only).
Reset configuration word source (MPC505/509 only)
•“Break In type.
The built-in “help cf” command also lists the following options, which
are provided only for compatibility with stand-alone emulation probes:
Trigger Out BNC.
Trigger In BNC.
•BNC break type.
The following option can be configured using built-in commands:
Restriction to real-time runs.
To configure the processor type
3URFHVVRUW\SHFRQILJXUDWLRQ
9DOXH 3URFHVVRUSUREHFRQILJXUHGIRU %XLOWLQFRPPDQG
03& 03& FISURF 03&
03& 03&'HIDXOW FISURF 03&
03& 03& FISURF 03&
