Making Connections
Connecting PC Cards
72 Corporate Evaluator’s Guide
Connecting PC Cards
The computer’s PC card slots are available for expanding the computer’s data storage
and communication capabilities. Your computer supports two standard Type II or one
Type III PC cards (PCMCIA and CardBus).
CAUTION
Do not remove a PC card while the computer is reading or writing data. If you do,
you could lose data, or the computer could stop responding.
To insert a PC card
1. Hold the card with its face up and its connector holes toward the card slot.
2. Slide the PC card all the way into the upper or lower slot. Most cards are properly
seated when the outer edge is flush with the casing of the computer, but some cards
are designed to protrude from the case.
To remove a PC card
CAUTION
Before removing a PC card, you must use the PC Card, Eject Hardware, or Safely
Remove Hardware icon in the taskbar, or else shut down the computer. Otherwise,
you could lose data.
1. Stop the PC card: double-click the PC card, Eject Hardware, or Safely Remove
Hardware icon in the taskbar, select the PC card you want to stop, then click Stop.
2. Flip the eject button out, so that it sticks out from the side of the computer.
3. Press the eject button and pull out the PC card.
