IP Routing Features
Configuring DHCP Relay
With validation enabled, the relay agent applies stricter rules to variations in
the Option 82 field(s) of incoming server responses to determine whether to
forward the response to a downstream device or to drop the response due to
invalid (or missing) Option 82 information. Table 3-5, below, describes relay
agent management of DHCP server responses with optional validation
enabled and disabled
Table 3-5. Relay Agent Management of DHCP Server Response Packets.
Response Packet Content Option 82
Configuration
Validation Enabled on the
Relay Agent
Validation Disabled
(The Default)
Valid DHCP server response
packet without an Option 82
field.
append, replace,
or drop
1
Drop the server response
packet.
Forward server response
packet to a downstream device.
keep
2
Forward server response
packet to a downstream device.
Forward server response
packet to a downstream device.
The server response packet
carries data indicating a given
routing switch is the primary relay
agent for the original client
request, but the associated
Option 82 field in the response
contains a Remote ID and Circuit
ID combination that did not
originate with the given relay
agent.
append Drop the server response
packet.
Forward server response
packet to a downstream device.
replace or drop
1
Drop the server response
packet.
Drop the server response
packet.
keep
2
Forward server response
packet to a downstream device.
Forward server response
packet to a downstream device.
The server response packet
carries data indicating a given
routing switch is the primary relay
agent for the original client
request, but the associated
Option 82 field in the response
contains a Remote ID that did not
originate with the relay agent.
append Drop the server response
packet.
Forward server response
packet to a downstream device.
replace or drop
1
Drop the server response
packet.
Drop the server response
packet.
keep
2
Forward server response
packet to a downstream device.
Forward server response
packet to a downstream device.
All other server response
packets
3
append, keep
2
,
replace, or drop
1
Forward server response
packet to a downstream device.
Forward server response
packet to a downstream device.
1
Drop is the recommended choice because it protects against an unauthorized client inserting its own Option 82 field for
an incoming request.
2
A routing switch with DHCP Option 82 enabled with the keep option forwards all DHCP server response packets except
those that are not valid for either Option 82 DHCP operation (compliant with RFC 3046) or DHCP operation without Option
82 support (compliant with RFC 2131).
3
A routing switch with DHCP Option 82 enabled drops an inbound server response packet if the packet does not have
any device identified as the primary relay agent (giaddr = null; refer to RFC 2131).
Multinetted VLANs
On a multinetted VLAN, each interface can form an Option 82 policy boundary
within that VLAN if the routing switch is configured to use IP for the remote
ID suboption. That is, if the routing switch is configured with IP as the remote
3-57

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
