HP ProCurve 2910al Switch User Manual

IP Routing Features
Configuring Static IP Routes
destination next-hop pair.
The following example configures two static routes for traffic delivery and
identifies two other null routes for which traffic should be discarded instead
of forwarded.
ProCurve(config)# ip route 10.10.40.0/24 10.10.10.1
ProCurve(config)# ip route 10.10.50.128/27 10.10.10.1
ProCurve(config)# ip route 10.10.20.177/32 reject
ProCurve(config)# ip route 10.10.30.0/24 blackhole
Configures static
routes to two different
network destinations
using the same next-
hop router IP address.
Configures a null route
to drop traffic for the
device at 10.50.10.177
and return an ICMP
notification to the
sender.
Configures a null route to drop traffic for the 10.50.10.0
network without any ICMP notification to the sender.
Figure 3-6. Example of Configuring Static Routes
Configuring the Default Route
You can also assign the default route and enter it in the routing table. The
default route is used for all traffic that has a destination network not reachable
through any other IP routing table entry. For example, if 208.45.228.35 is the
IP address of your ISP router, all non-local traffic could be directed to the ISP
by entering this command:
ProCurve(config)# ip route 0.0.0.0/0 208.45.228.35
3-26

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
