IP Routing Features

Configuring DHCP Relay

Displaying IRDP Information

To display IRDP information, enter show ip irdp from any CLI level.

ProCurve# show ip irdp

Status and Counters - ICMP Router Discovery Protocol

Global Status : Disabled

VLAN Name Status Advertising Min int Max int Holdtime Preference

Address (sec) (sec) (sec)

DEFAULT_VLAN Enabled multicast 450 600 1800 0

VLAN20 Enabled multicast 450 600 1800 0

VLAN30 Enabled multicast 450 600 1800 0

Figure 3-15.Example of Output for Show IP IRDP

Configuring DHCP Relay

Overview

The Dynamic Host Configuration Protocol (DHCP) is used for configuring

hosts with IP address and other configuration parameters without user inter-

vention. The protocol is composed of three components:

■ DHCP client

■ DHCP server

■ DHCP relay agent

The DHCP client sends broadcast request packets to the network; the DHCP

servers respond with broadcast packets that offer IP parameters, such as an

IP address for the client. After the client chooses the IP parameters, commu-

nication between the client and server is by unicast packets.

ProCurve routing switches provide the DHCP relay agent to enable commu-

nication from a DHCP server to DHCP clients on subnets other than the one

the server resides on. The DHCP relay agent transfers DHCP messages from

DHCP clients located on a subnet without a DHCP server to other subnets. It

also relays answers from DHCP servers to DHCP clients.

3-43
