Multimedia Traffic Control with IP Multicast (IGMP)
CLI: Configuring and Displaying IGMP
CLI: Configuring and Displaying IGMP
IGMP Commands Used in This Section
show ip igmp configuration page 2-7
ip igmp page 2-9
high-priority-forward page 2-11
auto <[ethernet] <port-list> page 2-10
blocked <[ethernet] <port-list> page 2-10
forward <[ethernet] <port-list> page 2-10
querier page 2-11
show ip igmp Refer to the section titled “Internet Group
Management Protocol (IGMP) Status” in appendix B
of the Management and Configuration Guide for your
switch.
Viewing the Current IGMP Configuration. This command lists the IGMP
configuration for all VLANs configured on the switch or for a specific VLAN.
Syntax:
show ip igmp config
Displays IGMP configuration for all VLANs on the switch.
show ip igmp vlan < vid > config
Displays IGMP configuration for a specific VLAN on the
switch, including per-port data.
(For IGMP operating status, refer to the section titled “Internet Group Man-
agement Protocol (IGMP) Status” in appendix B, “Monitoring and Analyzing
Switch Operation” of the Management and Configuration Guide for you
switch.)
2-7

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
