HP ProCurve 2910al Switch User Manual

IP Routing Features
Configuring RIP
■ Last update timeticks – How many seconds have passed since the
routing switch received an update from this neighbor.
Displaying RIP Redistribution Information
To display RIP redistribution information, enter the show ip rip redistribute
command at any context level:
ProCurve# show ip rip redistribute
RIP redistributing
Route type Status
--------- ----- -
connected enabled
static disabled
Figure 3-13. Example of Show IP RIP Redistribute Output
RIP automatically redistributes connected routes that are configured on
interfaces that are running RIP, and all routes that are learned via RIP. The
router rip redistribute command, described on page 3-31, configures the routing
switch to cause RIP to advertise connected routes that are not running RIP or
static routes. The display shows whether RIP redistribution is enabled or
disabled for connected or static routes.
Displaying RIP Redistribution Filter (restrict) Information
To display RIP restrict filter information, enter the show ip rip restrict command
at any context level:
ProCurve(config)# show ip rip restrict
RIP restrict list
IP Address Mask
--------------- --------------
Figure 3-14. Example of Show IP RIP Restrict Output
3-39

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
