IP Routing Features

Configuring RIP

The resulting display will appear similar to the following:

ProCurve# show ip rip peer

RIP peer information

IP Address Bad routes Last update timeticks

--------------- ----------- ---------------------

100.1.0.100 0 1

100.2.0.100 0 0

100.3.0.100 0 2

100.10.0.100 0 1

Figure 3-11. Example of Show IP RIP Peer Output

This display lists all neighboring routers from which the routing switch has

received RIP updates. The following fields are displayed:

■ IP Address – IP address of the RIP peer neighbor.

■ Bad routes – The number of route entries that were not processed for

any reason.

■ Last update timeticks – How many seconds have passed since the

routing switch received an update from this peer neighbor.

Displaying RIP information for a specific peer: For example, to show

the RIP peer information for the peer with IP address 100.1.0.100, enter show

ip rip peer 100.1.0.100.

ProCurve# show ip rip peer 100.0.1.100

RIP peer information for 100.0.1.100

IP Address : 100.1.0.100

Bad routes : 0

Last update timeticks : 2

Figure 3-12. Example of Show IP RIP Peer < ip-addr > Output

This display lists the following information for a specific RIP peer:

■ IP Address – IP address of the RIP peer neighbor.

■ Bad routes – The number of route entries which were not processed for

any reason.

3-38
