HP ProCurve 2910al Switch User Manual

Multimedia Traffic Control with IP Multicast (IGMP)
How IGMP Operates
ProCurve(config)# show igmp-proxy vlans
IGMP PROXY VLANs
VID Multicast Domain Active entries
------ ---------------- --------------
1 George 1
1 Sam 1
1 Jane 0
2 George 1
4 George 0
4 Bill 0
Figure 2-9. Example Showing Active IGMP Proxy VLANs
Operating Notes for IGMP Proxy Forwarding
■ You can configure up to 12 multicast domains. These domains will indicate
a range of multicast addresses and the IP address of the PIM-SM/PIM-DM
border router.
■ You must give each domain a unique name, up to 20 characters long.
■ The domains may have overlapping multicast ranges.
■ The IP address of the border router may be the same or different in each
configured domain.
■ Duplicate IGMP joins are automatically prevented, or leaves that would
remove a flow currently joined by multiple hosts.
■ Range overlap allows for redundant connectivity and the ability for mul-
ticasts to arrive from different border routers based on the shortest path
back to the source of the traffic.
■ The configured domain names must be associated with one or more
VLANs for which the proxy joins are to be done.
■ All routers in the path between the edge router receiving the initial IGMP
packets and the border router have to be configured to forward IGMP
using IGMP proxy.
■ All upstream and downstream interfaces using IGMP proxy forwarding
require IGMP and PIM to be enabled.
■ You must remove all VLAN associations with the domain name before that
domain name can be removed.
2-24

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
