HP ProCurve 2910al Switch User Manual

IP Routing Features
Configuring RIP
RIP Information Type Page
Redistribute Information
3-39
Restrict Information
3-39
Displaying General RIP Information
To display general RIP information, enter show ip rip at any context level. The
resulting display will appear similar to the following:
Figure 3-7.Example of General RIP Information Listing
The display is a summary of Global RIP information, information about
interfaces with RIP enabled, and information about RIP peers. The following
fields are displayed:
■ RIP protocol – Status of the RIP protocol on the router. RIP must be
enabled here and on the VLAN interface for RIP to be active. The default
is disabled.
■ Auto-summary – Status of Auto-summary for all interfaces running RIP.
If auto-summary is enabled, then subnets will be summarized to a class
network when advertising outside of the given network.
3-34

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
