HP ProCurve 2910al Switch User Manual

IP Routing Features
Configuring Static IP Routes
Disabling ICMP Redirects
You can disable ICMP redirects on the ProCurve routing switch only on a
global basis, for all the routing switch interfaces. To disable ICMP redirects
globally, enter the following command at the global CONFIG level of the CLI:
ProCurve(config)# no ip icmp redirects
Syntax: [no] ip icmp redirects
Configuring Static IP Routes
This feature enables you to create static routes (and null routes) by adding
such routes directly to the route table. This section describes how to add static
and null routes to the IP route table.
Static Route Types
You can configure the following types of static IP routes:
■ Standard – the static route consists of a destination network address or
host, a corresponding network mask, and the IP address of the next-hop
IP address.
■ Null (discard) – the Null route consists of the destination network
address or host, a corresponding network mask, and either the reject or
blackhole keyword. Typically, the null route is configured as a backup
route for discarding traffic if the primary route is unavailable. By default,
when IP routing is enabled, a route for the 127.0.0.0/8 network is created
to the null interface. Traffic to this interface is rejected (dropped). This
route is for all traffic to the “loopback” network, with the single exception
of traffic to the host address of the switch’s loopback interface (127.0.0.1/
32). Figure 3-6 on page 3-26 illustrates the default Null route entry in the
switch’s routing table.
Note On a single routing switch you can create one null route to a given destination.
Multiple null routes to the same destination are not supported.
3-22

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
