HP ProCurve 2910al Switch User Manual

1
Getting Started
Need Only a Quick Start?
Need Only a Quick Start?
IP Addressing
If you just want to give the switch an IP address so that it can communicate
on your network, or if you are not using VLANs, ProCurve recommends that
you use the Switch Setup screen to quickly configure IP addressing. To do so,
do one of the following:
■ Enter setup at the CLI Manager level prompt.
Procurve# setup
■ In the Main Menu of the Menu interface, select
8. Run Setup
For more on using the Switch Setup screen, see the Installation and Getting
Started Guide you received with the switch.
To Set Up and Install the Switch in Your
Network
Physical Installation
Use the ProCurve Installation and Getting Started Guide for the following:
■ Notes, cautions, and warnings related to installing and using the switch
and its related modules
■ Instructions for physically installing the switch in your network
■ Quickly assigning an IP address and subnet mask, set a Manager pass-
word, and (optionally) configure other basic features.
■ Interpreting LED behavior.
For the latest version of the Installation and Getting Started Guide for your
switch, refer to “Getting Documentation From the Web” on page 1-6.
1-8

HP ProCurve 2910al Switch Specifications

General

Model	HP ProCurve 2910al Switch
Layer	Layer 3
Jumbo Frame Support	Yes
Power Device	Internal power supply
VLAN Support	Yes
Power Supply	100-240 VAC, 50/60 Hz
Ports	24 or 48 x 10/100/1000 ports
Uplink Ports	4 x SFP (mini-GBIC)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF, BGP, IGMP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP
Features	VLAN, QoS, IPv6, ACLs
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af
Operating Temperature	0 to 45°C
Operating Humidity	15% to 95% (noncondensing)
Power over Ethernet (PoE)	PoE+ (802.3at) on PoE+ models, PoE (802.3af) on PoE models
