Installing the M.2 SSD/dedicated iLO/serial port enablement boardInstalling the M.2 SSD/dedicated iLO/serial port enablement board
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the following tools available:
T-15 Torx screwdriver
4.5 mm hex nut screwdriver
ProcedureProcedure
1. If installed, remove the front bezel .
2. Power down the server.
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5. Remove the server from the rack .
6. Remove the access panel .
7. Remove the riser cage.
8. Remove the iLO dedicated network port blank.
9. Remove the M.2 air guider.
