HP ProLiant DL20 Gen10 - Optical Drive Cabling

To Next Page

To Previous Page

Optical drive cablingOptical drive cabling

LFF configurationLFF configuration

Cable colorCable color DescriptionDescription

Orange SATA-power Y-cable to x1 SATA port 2

Blue Power extension cable

SFF configurationSFF configuration

Cable colorCable color DescriptionDescription

Orange SATA-power-Y cable to x1 SATA port 2

Optical drive cabling 181
