HP ProLiant DL20 Gen10 - Installing an M.2 SATA SSD

Installing an M.2 SATA SSDInstalling an M.2 SATA SSD
The M.2 SATA expansion board supports 2280 or 22110 M.2 SSDs only.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the following tools available:
T-15 Torx screwdriver
Phillips No. 1 screwdriver
ProcedureProcedure
1. If installed, remove the front bezel .
2. Power down the server.
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5. Remove the server from the rack .
6. Remove the access panel .
7. Remove the riser cage.
8. If you are installing the M.2 SATA SSD enablement board in the PCIe riser slot 1, do the following:
a. Remove the full-height bracket from the enablement board.
b. Install the low-profile bracket on the enablement board.
Installing an M.2 SATA SSD 122
