4+2 bay SFF hot-plug drive cabling4+2 bay SFF hot-plug drive cabling
4+2 bay SFF hot-plug drive for embedded controller cabling4+2 bay SFF hot-plug drive for embedded controller cabling
Cable colorCable color DescriptionDescription
Orange Four-bay SFF drive backplane power cable
Blue Mini-SAS cable
Gold Two-bay SFF to four-bay SFF drive backplane power cable
Pink SATA cable and drive sideband cable
4+2 bay SFF hot-plug drive for Smart Array modular controller (AROC) cabling4+2 bay SFF hot-plug drive for Smart Array modular controller (AROC) cabling
Cable colorCable color DescriptionDescription
4+2 bay SFF hot-plug drive cabling 174
