HP ProLiant DL20 Gen10 - Two-Bay LFF Hot-Plug Drive Cabling

Two-bay LFF hot-plug drive cablingTwo-bay LFF hot-plug drive cabling
Two-bay LFF hot-plug drive for embedded controller cablingTwo-bay LFF hot-plug drive for embedded controller cabling
Cable colorCable color DescriptionDescription
Orange Two-bay LFF drive backplane power cable
Blue Mini-SAS cable
Two-bay LFF hot-plug drive for Smart Array modular controller (AROC) cablingTwo-bay LFF hot-plug drive for Smart Array modular controller (AROC) cabling
Cable colorCable color DescriptionDescription
Orange Mini-SAS cable from drive backplane to AROC port 1
Two-bay LFF hot-plug drive cabling 170
