A EVA4400 cabling diagrams
This appendix contains cabling diagrams for common EVA4400 installation environments. If you plan
to configure the EVA4400 with an iSCSI device, see the HP StorageWorks EVA iSCSI connectivity
user guide.SeeRelated documentation for the location of this guide.
Connecting device port Fibre Channel cables to the EVA4400
(rear view)
This section shows two views of how you can connect cables to the controller. Figure 22 shows the
controller mounted on top of the disk shelves in the rack, and Figure 23 shows the controller with disk
shelves mounted above and below it.
1. For configurations with the controller above the disk enclosures, attach the cables to the EVA as
shown in Figure 22.
NOTE:
All controller device port A cabling must be plugged into the A I/O modules on all enclosures.
All controller B device port cabling must be plugged into the B I/O modules on all enclosures.
HP StorageWorks 4400 Enterprise Virtual Array installation guide 81
