Technical specifications
Physical specifications
Table 21: Physical specifications
Characteristic Product alone Packaged
Height 133 mm 320 mm
Width 482 mm 690 mm
Depth 875 mm 1160 mm
Weight Base module: 20 kg
Expansion module: 14 kg
Base module: 31 kg
Expansion module: 24 kg
Environmental specifications
Table 22: Environmental specifications
Characteristic Specification
LTO-7 and LTO-8 LTO-5 and LTO-6
Temperature
Operating 10° to 35° C up to 3000m
10° to 30° C above 3000m and up to
4000m
10° to 35° C
Storage -30° to 60° C
Temperature shock
immunity — maximum rate
of change
10° C per hour
Miscellaneous
Dust concentration ISO 14644 -1 Class 8 less than 200 microgram / cubic
meter
Altitude 4000 meters (see operating
temperature)
4000 meters
Humidity
Table Continued
238 Technical specifications
