16 PRODUCT OVERVIEW
Product Features
Exploded View
The following image shows a typical HP Workstation xw8200. Drive configurations can vary.
For complete and current information on supported accessories and components, visit
http://partsurfer.hp.com
.
Table 1-1 Exploded View
1 Memory Modules 6 Front Bezel 11 Access Panel
2 System Fan 7 Hard Drive 12 Processors
3 Power Supply 8 System Board 13 CPU Heatsinks
4 Chassis 9 PCI Card
5 Optical Drive* 10 PCI-E (graphics)
*An optical drive is a CD-ROM, CD-R/RW, DVD-ROM, DVD+R/RW, or CD-RW/DVD combo drive.
12 3 4
5
6
7910
11
12
13
8
